Architecture ≤ v2.x

Warning

digidocu < v3 is deprecated

➩ no development anymore
➩ only limited support

Description

digidocu is a rich web application that can be used to create redundancy-free, multilingual documentation. It uses a hierarchical grid system with classes | subclasses, rooms, languages, categories | subcategories.

User Interfaces

Frontends (User Interfaces) interchangeable

Version 1.x: Vanilla JS
Version 2.x: Vanilla JS, Login: Angular (v11)
Admin UI:
- Admin interfaces in Version 1.x: fixed Vanilla JS
- Admin interfaces in Version 2.x: Vue.js

Middleware (Web Application Server)

Version 1.x: C++17 / QT5
Version 2.x: C++20 / QT6

Details

∗ defaults

Frontend

default: Internet Browser-based (HTML5 responsive web design; standard: component-based SPA, optional PWA).
based on CRUD + POST
based on JSON

All other frontends are optional.

UX

UX: User Experience = UI: User Interface + UD: User Design

UI: Angular (default), Admin-Interfaces: Vue
UD: NG-Zoro (Ant Design of Angular, default), Admin-Interfaces: Ionic

JavaScript Server

default: Node.js
preferred: Deno.js

Container

default: Docker
preferred: Podman

Web-Applicationserver

default: container with Linux
optional: (container with) MacOS or Windows
recommended: (container with) Linux (same for Databases)
